Industrial High Temp Thermal Camera

FLIR TG297

Go to Product Support
product image

The FLIR TG297 is a one-of-a-kind industrial diagnostic tool that combines accurate temperature measurement with the ability to image up to 1030°C (1886°F). Patented FLIR MSX® (Multi-Spectral Dynamic Imaging) enhancement improves image clarity by embossing visual scene details on full thermal images. The TG297 is ideal for high-temperature industrial uses such as measuring the heat of glass furnaces, kilns, and forges as well as manufacturing applications, allowing you to accurately target potential faults, troubleshoot repairs, and monitor processes. Record images to assure your team that machinery and systems are functioning safely and at peak efficiency.

$729.00
Buy Now
Product Shipping FREE Shipping
Product Returns Shipping & Returns
Sales Contact Contact Sales

Designed for Affordable Industrial High-Temp Imaging

  • Identify Problems Quickly

    Measure a wide range of temperatures from -25°C to 1030°C (-13°F to 1886°F) with a true 160 × 120 IR pixel imager (19,200 pixels)

  • Produce Crisp Thermal Images

    Diagnose problems faster on extreme heat targets by engaging the high temperature filter over the lens to create a detailed image

  • Work with Confidence in Rugged Environments

    Work from a safe distance to measure high-temperature objects (e.g. a glass furnace) with a portable tool protected by an IP54 enclosure







get inspection information to the people you need

FLIR METERLiNK® App

The FLIR METERLiNK® app allows you to monitor a variety of environmental and electrical conditions simultaneously with the ability to connect with up to seven FLIR compatible meters at once. METERLiNK allows you to safely capture images and monitor hazardous areas remotely and in real time. Whether you're connecting several FLIR clamp meters, digital multimeters, or any of the new METERLiNK app compatible meters, you will be able to keep tabs on key readings around your facility and easily share them with your team.

Learn More

Sale pricing valid for U.S. only

Contact Sales

Want more information on this product?

Call (866) 477-3687 to speak with a knowledgeable specialist.

Specifications
IR Resolution
160 × 120 pixels
Thermal Sensitivity/NETD
<70 mK
Accuracy
±1.5°C (2.7°F) for temperatures 50°C to 100°C (122°F to 212°F); up to ±3°C (±5.4°F) for -25°C to 50°C (-13°F to 122°F) and 100°C to 1030°C (212°F to 1886°F)
Field of view (FOV)
57° × 44°
Image Modes
• MSX® (Multi Spectral Dynamic Imaging) • Visual with temperature reading
Display
320 × 240 pixel, 2.4 in color LCD
Storage Media
eMMC 4 GB
Imaging & Optical
Built-in Digital Camera
Yes
Color Palettes
Iron, Rainbow, White hot, Black hot, Arctic, Lava
Detector Pitch
12 µm
Detector Type
Focal plane array (FPA), uncooled microbolometer
Digital image enhancement
Yes
Field of view (FOV)
57° × 44°
Focus
Focus free
Gallery
Yes
Image Frequency
8.7 Hz
Image Modes
• MSX® (Multi Spectral Dynamic Imaging) • Visual with temperature reading
IR Resolution
160 × 120 pixels
Laser
Class 1 laser indicates the temperature measurement area; button-activated
Minimum Focus Distance
0.3 m (0.98 ft)
Minimum Measurement Distance
0.26 m (0.85 ft)
Spectral Range
7.5 - 14 µm
Thermal Sensitivity/NETD
<70 mK
Measurement & Analysis
Accuracy
±1.5°C (2.7°F) for temperatures 50°C to 100°C (122°F to 212°F); up to ±3°C (±5.4°F) for -25°C to 50°C (-13°F to 122°F) and 100°C to 1030°C (212°F to 1886°F)
Camera size (L x W x H)
210 × 64 × 81 mm (8.3 × 2.5 × 3.2 in)
Camera weight incl battery
0.394 kg (13.9 oz)
Center spot
Yes
Emissivity Correction
Yes: 4 preset levels with custom adjustment of 0.1–0.99
Object Temperature Range
-25°C to 1030°C (-13°F to 1886°F)
Set-up Commands
• Local adaptation of units, language, date, and time formats • Screen brightness (high, medium, low) • Gallery, deletion of images
Spot Meter
Center spot on/off
User Interface
Display
320 × 240 pixel, 2.4 in color LCD
Languages
Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Russian, simplified Chinese, Spanish, Swedish, traditional Chinese, Turkish.
Power
Battery charge life
30 days minimum
Battery operating time
5 hours continuous scanning, 4.5 hours with laser on
Battery type
Rechargeable Li ion battery
Battery voltage
3.7 V
Charging system
Battery is charged inside the camera
Charging Temperature
0°C to 45°C (32°F to 113°F)
Charging Time
4 hours to 90%, 6 hours to 100%
Power Management
Adjustable: off, 5 min., 15 min., 30 min.
Environmental & Certifications
Drop test
Designed for 2 m (6.6 ft)
EMC
• EN 61000-6-3 • EN 61000-6-2 • FCC 47 CFR Part 15 Class B
Encapsulation
IP 54 (IEC60529)
Humidity (Operating and Storage)
0-90% RH (0-37°C (32-98.6°F)), 0-65% RH (37-45°C (98.6-113°F)), 0-45% RH (45-55°C (113-131°F))
Operating Temperature Range
-10°C to 45°C (14°F to 113°F)
Radio Spectrum
• ETSI EN 300 328 • FCC Part 15.249 • RSS-247 Issue 2 • EN 301 489-1:2011 • EN 301 489-17:2009
Safety
CE/CB/EN61010/UL
Shock
25 g (IEC 60068-2-27)
Storage Temperature Range
-30°C to 55°C (-22°F to 131°F)
Tripod Mounting
1/4 in.-20 on handle bottom
Vibration
2 g (IEC 60068-2-6)
Warranty
FLIR 2-10 warranty
General
Includes
TG297, printed documentation, wrist strap lanyard, USB A to USB C cable, carry pouch
